Super Duralumin Forged Aluminium Alloy Billet 2025 For Aeroplane Propeller

MOQ:	1PCS
Price:	Negotiations
Standard Packaging:	wooden pallet
Delivery Period:	20~30days
Payment Method:	T/T, L/C
Supply Capacity:	5000 per month

Details Information

Product Description

Detail Information

Place of Origin

CHINA

Brand Name

Certification

ISO9001-2008,SGS,ROHS.

Model Number

Application:

Aeroplane Propeller

Name:

2025 Forged Aluminum

Standard:

JIS, DIN, BS, ASTM, SAE.

Type:

Casting Forging

Technics:

Forge, CNC

Alloy:

Max Diameter:

1320mm

Highlight:

Forged Aluminium Alloy Billet

Aluminium Alloy Billet 2025

Aeroplane Aluminium Alloy Duralumin

Product Description

Super Duralumin Aluminium Forged Products Billet 2025 For Aeroplane Propeller

2025 forged aluminum Quickly details

Alloy: 2025:
Temper:T6,T852,T652
Temper: T6 : Usually don't special-purpose alloy forging. High strength.
Max diameter: 1320mm.
Max length : 7500mm.
The density:2.77kg/m3

2025 aluminum alloy T6 Mechanical properties:

Tensile strength

(kg/mm2)

yield point, elongation(kg/mm2)

Elongation(%)

brinell hardness

shear strength(kg/mm2)

fatigue strength(kg/mm2)

10.78

26.01

110

24.61

12.66

Normal size:Φ166,Φ220,Φ380,Φ396,Φ448,Φ462,Φ566,Φ582,Φ915,Φ1060,Φ1220,Φ1320

Features:

Large specification :the produced billetφ1320mm is the largest billet in the world.

The max : weight of the billet up to 12.5 ton.

High purity : low hydrogen, low dross, low alkali content inside the ingot .

high-homogeneity : composition & organization, Small degree of segregation.small grain

size difference between core and surface.

Fine grain size.

Availability of product with the hydrogen content ≤0.08ML/100gAl.

Availability of product with porosity at class one .

Availability of product with oxidation film at the class one.

Availability of product with ultrasonic flaw detection at level A.

2025 forged aluminum Application:

Aeroplane propeller

2025 Chemical Composition Standard.

Cu	Mg	Mn	Fe	Si	Zn	Ti	Cr	Other	Al
3.8-4.9	1.2-1.8	0.3-0.9	0.5	0.5	0.25	0.15	0.1	<0.05	Balance

2025 forged aluminum alloy & forging product size.

Alloy	2025 forged aluminum Products size
Alloy	Diameter (mm)	Max. length (mm)
2xxx/2025	Φ166	7500
	Φ220	7500
	Φ380	7500
	Φ396	7500
	Φ448	7500
	Φ462	7500
	Φ566	7500
	Φ582	7500
2xxx/2025	Φ915	4500
	Φ1060	4000
	Φ1220	4000
	Φ1320	3500

Remark:

1. Billet peeling is available.
2. The cut-to-length product is available upon to customer’s request.

Aluminium forging alloy & forging product application.

Alloy	forging product application
2025	Aeroplane propeller
