Alloy: 2219 LY19 A2219 EN AW-2219 AlCu6Mn 5004A A92219
Deformation of 2219 aluminum alloy, the aluminum and aluminum alloy.
The corrosion resistance of 2219 aluminum alloy is poor, good machining performance;
Poor brazing, easy arc welding and spot welding. Suitable for working under high temperature 315 ℃ of structure, high strength welding parts.
Temper: F,O, T6
Max diameter: 1320mm.
Max length : 7500mm.
The density:2.77kg/m3
Standard :UNS A92219,ISO R209 AlCu6Mn；CHINA GB 2219(LY19)
Normal size:Φ166,Φ220,Φ380,Φ396,Φ448,Φ462,Φ566,Φ582,Φ915,Φ1060,Φ1220,Φ1320

2219 aluminum forging Application:

The rocket liquid fuel tank,
work structure for long time high temperature ,
welding structure,
vehicle material

2219 aluminum alloy Chemical Composition Standard

Cu	Mg	Mn	Fe	Si	Zn	Ti	Zr	Other	Al
5.8-6.8	0.02	0.2-0.4	0.3	0.2	0.1	0.02-0.1	0.1-0.25	<0.15	Balance

Alloy 2219-T6 Mechanical properties

Tensile strength

(kg/mm2)

yield point, elongation(kg/mm2)

Elongation(%)

brinell hardness

shear strength(kg/mm2)

fatigue strength(kg/mm2)

31.6

115

10.5

2219 aluminum forging product size.

Alloy	Products size
Alloy	Diameter (mm)	Max. length (mm)
2xxx 2219 LY19 AlCu6Mn A2219 EN AW-2219 5004A A92219	Φ166	7500
	Φ220	7500
	Φ380	7500
	Φ396	7500
	Φ448	7500
	Φ462	7500
	Φ566	7500
	Φ582	7500
2xxx 2219 LY19 AlCu6Mn A2219 EN AW-2219 5004A A92219	Φ915	4500
	Φ1060	4000
	Φ1220	4000
	Φ1320	3500

Remark: 1. Billet peeling is available.
2. The cut-to-length product is available upon to customer’s request.

2219Aaluminum forging application

Alloy	forging product application
2219	The rocket liquid fuel tank, work structure for long time high temperature ,welding structure, vehicle material

Aluminum forging application

2219 Aluminium Forgings LY19 EN AW 2219 AlCu6Mn 5004A A92219 0
