Alloy: 5456, AlMg5Mn1, A5456, EN AW-5456A/AlMg5Mn (Note: Corrosion resistance is not high)
Maximum Diameter: 1320mm
Maximum Length: 7500mm
Standard Sizes: Φ166, Φ220, Φ380, Φ396, Φ448, Φ462, Φ566, Φ582, Φ915, Φ1060, Φ1220, Φ1320
Standard: GB/T 3191-1998

Primary Applications

Military rocket trajectory ballistic fist-size pile piece, marine high strength welded structures

Key Features

Large Specifications: Produced billet φ1320mm is the largest billet in the world
Maximum Weight: Up to 12.5 tons
High Purity: Low hydrogen, low dross, low alkali content
High Homogeneity: Uniform composition & organization, minimal segregation
Fine Grain Structure: Small grain size difference between core and surface
Hydrogen Content: ≤0.08ML/100gAl
Porosity: Class one quality
Oxidation Film: Class one quality
Ultrasonic Testing: Level A flaw detection standard

Chemical Composition Standard

Cu	Mg	Mn	Fe	Si	Zn	Ti	Cr	Other	Al
0.1	4.7-5.5	0.5-1.0	0.4	0.25	0.25	0.2	0.05-0.2	<0.15	Balance

Packaging: Wooden pallet

Forging Alloy & Product Size Specifications

Alloy	Diameter (mm)	Maximum Length (mm)
5456	Φ166	7500
	Φ220	7500
	Φ380	7500
	Φ396	7500
	Φ448	7500
	Φ462	7500
	Φ566	7500
	Φ582	7500

Remarks: 1. Billet peeling is available.
2. Cut-to-length products available upon customer request.

Aluminum Forging Alloy Applications

Alloy	Forging Product Application
5456	Military rocket trajectory ballistic fist-size pile piece, marine high strength welded structures
