Alloy: 6005A
Maximum Diameter: 1320mm
Maximum Length: 7500mm
Standard Sizes: Φ166, Φ220, Φ380, Φ396, Φ448, Φ462, Φ566, Φ582, Φ915, Φ1060, Φ1220, Φ1320
Standard: GB/T 3191-1998

Key Features

Large Specification: Produced billet φ1320mm is the largest in the world
Maximum Weight: Up to 12.5 tons per billet
High Purity: Low hydrogen, low dross, low alkali content
High Homogeneity: Uniform composition and organization with minimal segregation
Fine Grain Size: Minimal grain size difference between core and surface
Hydrogen Content: ≤0.08ML/100gAl
Porosity: Class one quality
Oxidation Film: Class one quality
Ultrasonic Flaw Detection: Level A standard

Applications

Supercharger fans, high-speed train carriage materials, transportation machinery parts, and related components.

Chemical Composition Standard

Element	Cu	Mg	Mn	Fe	Si	Zn	Ti	Cr	Other	Al
Content (%)	0.3	0.4-0.7	0.5	0.35	0.5-0.9	0.20	0.10	0.3	<0.15	Balance

Available Sizes

Alloy	Diameter (mm)	Maximum Length (mm)
6xxx	Φ166	7500
	Φ220	7500
	Φ380	7500
	Φ396	7500
	Φ448	7500
	Φ462	7500
	Φ566	7500
	Φ582	7500

Additional Options:
1. Billet peeling service available
2. Cut-to-length products available upon customer request

Packaging

Wooden pallet packaging for secure transportation and storage.
