High Purity 6061 T6 Billet Aluminum Forgings LD30 AlSi1MgCu
  • name

High Purity 6061 T6 Billet Aluminum Forgings LD30 AlSi1MgCu

MOQ: 1PCS
Price: Negotiations
Standard Packaging: wooden pallet
Delivery Period: 20~30days
Payment Method: T/T, L/C
Supply Capacity: 1000 per month
Detail Information
Product Description
Detail Information
Place of Origin
CHINA
Brand Name
JIMA
Certification
ISO9001-2008,SGS,ROHS.
Model Number
6005A
Application:
Truck Component, Automobile Hub, Flange, Chemical Industry & Water Heater
Name:
6061 Super Duralumin Aluminum Alloy Billet For Forging
Standard:
JIS, DIN, BS, ASTM, SAE.
Type:
Casting Forging
Technics:
Forge, CNC
Alloy:
6061-t6
Highlight:

6061 T6 Billet Aluminum

,

Aluminum Alloy 6061 LD30

,

6061 T6 Aluminum Forgings

Product Description
High Purity 6061 T6 Billet Aluminum Forgings LD30 AlSi1MgCu
High Purity 6061 T6 Billet Aluminum, Aluminum Alloy 6061 LD30 AlSi1MgCu
Applications
Truck components, automobile hubs, flanges, chemical industry equipment, and water heaters
Product Specifications
Alloy: 6061
Temper: T6, T652
Maximum Diameter: 1320mm
Maximum Length: 7500mm
Standard Sizes: Φ166, Φ220, Φ380, Φ396, Φ448, Φ462, Φ566, Φ582, Φ915, Φ1060, Φ1220, Φ1320
International Standards
German Standard: AlMgSi1Cu/3.3211 DIN 1725.1-1986/W-Nr.
French Standard: 6061(A-GSUC) NF A50-411 NF A50-451
British Standard: 6061(N20/H20) BS 1470-1988
American Standard: 6061/A96061 AA/UNS
Key Features
  • Large specification range: φ1320mm is the world's largest billet diameter
  • Maximum billet weight up to 12.5 tons
  • High purity with low hydrogen, low dross, and low alkali content
  • High homogeneity in composition and microstructure
  • Minimal segregation with small grain size difference between core and surface
Chemical Composition
CuMgMnFeSiZnTiCrOtherAl
0.15-0.40.8-1.20.150.70.4-0.80.250.150.04-0.35<0.15Balance
Mechanical Properties (6061-T6 / 6061-T652)
Tensile Strength (kg/mm²)Yield Point (kg/mm²)Elongation (%)Brinell HardnessShear Strength (kg/mm²)Fatigue Strength (kg/mm²)
33301710021.89.8
Material Summary
6061 aluminum alloy is a high-quality product manufactured using pre-tension heat treatment technology. While its strength may not match 2XXX or 7XXX series alloys, it offers superior magnesium-silicon alloy characteristics including excellent machining performance, outstanding welding and electroplating capabilities, good corrosion resistance, high toughness after deformation, dense material free from defects, easy polishing, and excellent anodizing results.
6061 Aluminum Alloy Characteristics
6061-T651 aluminum is a premium magnesium-aluminum alloy processed with pre-stretching heat treatment. It features excellent machining performance, good corrosion resistance, high post-processing toughness, and superior anodizing and coloring capabilities.
Primary Applications
Widely used in industrial structures requiring specific strength and high corrosion resistance, including truck manufacturing, tower construction, vessels, trolleys, and railway vehicles.
Typical Applications
Aerospace components, electrical fixtures, communication equipment, automated machinery parts, precision machining, mold manufacturing, electronics, precision instruments, SMT solder applications, and PC board vehicles.
Packaging
Wooden pallet
Frequently Asked Questions
Q1: Can you supply samples?
A: We can supply samples for quality verification before bulk orders.
Q2: Is zinc-free copper foil available?
A: Yes, zinc-free copper foil is available.
Q3: Can you provide Certificate of Analysis (COA)?
A: Yes, we can provide COA.
Q4: How long to receive samples?
A: 7 days for sample delivery.
Q5: Quantity for 20'GP container?
A: Approximately 17-20 metric tons.
Q6: How many staff do you have?
A: We employ 380 workers.
Aluminum Forging Alloys & Applications
AlloyForging Product Application
2024Airplane, truck hub, ordnance, railway vehicles, machine structure
2025Aeroplane propeller
2218Airplane engine cylinder head and piston
2219Rocket liquid fuel tanks, high-temperature structures, welding structures, vehicle materials
2618Airplane cylinder head and piston hub, jet motor accessories, rubber molds, heat-resistant parts
5083Military ballistic rocket parts, marine structures, LNG flange plates, petrochemical machinery, ship components, desalination structures
5056LNG flange plates, petrochemical machinery, ship components, desalination structures
5456Military rocket components, marine high-strength welded structures
6061Truck components, automobile hubs, flanges, chemical industry & water heaters
6070Aerospace, large automotive vehicles, railway vehicle materials & rotor parts
6082
6005ASupercharger fans, high-speed train carriage materials, transportation machinery parts
6151Airplane engine boxes, auto parts, machine parts
7049Aerospace vehicle structures
7079Skeleton large forgings
7075Airplane, ship, auto parts, structural members
7175
7475
7050High-stress components, aerospace materials, important structural materials
7150
Tags:

Forged Metal Parts,

Forged Metal Components,

Metal Forgings
