MOQ:	1PCS
Price:	Negotiations
Standard Packaging:	Standard Export Wooden Pallet
Delivery Period:	10~20days
Payment Method:	T/T, L/C
Supply Capacity:	10000pcs /per month

Detail Information

Product Description

Detail Information

Place of Origin

CHINA

Brand Name

JIMA

Certification

ISO9001-2008,SGS,ROHS.

Model Number

ALP

Application:

Airplane Cylinder Head And Piston

Name:

OEM 2218 Forged Aluminum Metal Parts For Airplane Cylinder Head And Piston,Metal Parts,Forging Parts

Standard:

JIS, DIN, BS, ASTM, SAE.

Alloy:

AL2218

Sample:

Can Be Customized

Surface Treatment:

Anodizing,Plating,Satin,Painting,Powder Coating,Anodized Etc

Process:

Forging

Mold:

Can Be Customized

Highlight:

OEM Forged Aluminum Parts

2218 Forged Aluminum Parts

Airplane Cylinder Head Aluminum Metal Parts

Product Description

OEM 2218 Forged Aluminum Parts For Airplane Cylinder Head And Piston

High-quality forged aluminum alloy 2218 components specifically engineered for aircraft cylinder heads and pistons, offering superior strength and durability for aerospace applications.

Product Specifications

Material	Aluminum Alloy 2218
Process	Forging + CNC + Heat Treatment
Surface Treatment	Transparent; Color Anodized; Hard Anodizing; Powder Coating; Sandblasting, Laser Carving, Silk Screening; Nickel-Plated, Chrome, Galvanized, Silver/Gold Plating; Black Oxide Coating; Polishing; etc.
Manufacture Ability	Depends on The Complexity Of Different Products And Quantities
Experience	Aluminum Machining Service for 12 Years
Packaging	Standard Export Wooden Pallets Another Request According to Your Need
MOQ	1pcs
Sample	Can be Customized
Mold	Can be Customized
Lead Time	Mold for 15-20 Days Process for 15-20 Days
OEM	Can be Customized

Chemical Composition of 2218 Aluminum Alloy

Element	Content (%)
Si	0.9
Fe	1.0
Cu	3.5~4.5
Mn	0.2
Mg	0.2~1.8
Cr	0.1
Ni	1.7~2.3
Zn	0.25
Others (Each)	0.05
Others (Total)	0.15
Al	Rest

Physical Properties

Property	Metric	Imperial
Density	2.82 g/cm³	0.102 lb/in³
Melting Point	507 - 638°C	945 - 1180°F

Mechanical Properties (T61 Temper)

Property	Value	Conditions
Tensile Strength	405 MPa	25°C
Yield Strength	305 MPa	25°C
Hardness (HB500)	115	25°C
Shear Strength (T72)	205 MPa	25°C
Elastic Modulus	70-80 GPa	25°C
Poisson's Ratio	0.33	25°C

Thermal Properties

Property	Value	Conditions
Thermal Expansion	22.3 × 10⁻⁶/ºC	20-100°C
Thermal Conductivity	148 W/m·K	25°C, T61

Electric Properties

Property	Value	Conditions
Electric Resistivity	45 × 10⁻⁹ Ω·m	25°C, T61

Forging Specifications

Type	Alloy	Projected Area/Weight	Temper	Standard
Free forgings	5 series	≤3000kg	O,F	GBn223, ASTMB247
Free forgings	2,6,7 series	≤3000kg	T6,T4,O,F	GBn223, ASTMB247
Mold forgings	5 series	≤2.5m²	O,F	GBn223, ASTMB247
Mold forgings	2,6,7 series	≤2.5m²	T6,T4,O,F	GBn223, ASTMB247

Standard Specifications

DIN 3.1924
DTD 717A
DTD 731B
DTD 745A
DTD 5070B
DTD 5014
DTD 5084A
MSRR 8018
MSRR 8016
BS Pre-1980 H16
CM001-1 T6
CM001-3 H28
Hiduminium 58
GB-D19S
SO7-1103 (S07-1103)
A-U2GN
UNI 9002/6
L-3171
CCT LA 767
AIRBUS-ABM1-1006
BAEM 1101
BAEM 1103
MM 0531
AIR 9048.640 T351
AIR 9048.640 T851
AIR 9051A
AIR 9048.150
AIR 9048.170
AIR 9048.640
Werkstoff Nr. 3.1924 T651
EN 2123 T351
EN 2123 T851
EN 3553 T6511
ASN-A-3355
ASN-A-3357

Product Showcase
