Precision Waterjet Cutting Services Stainless Steel Bearing Rings HRC 58-60 Hardness
  • name
  • name

Precision Waterjet Cutting Services Stainless Steel Bearing Rings HRC 58-60 Hardness

MOQ: 1PCS
Standard Packaging: Standard Export Package
Detail Information
Product Description
Detail Information
Place of Origin
CHINA
Brand Name
JIMAFor
Certification
ISO9001-2008,SGS,ROHS.
Product Name:
Precision Waterjet-Cut Stainless Steel Bearing Rings (440C) | ±0.05mm Tolerance | HRC 58-60 Hardness
Sample:
Free Supply
Applications:
Marine & Offshore: Propulsion Systems, Saltwater-resistant Assemblies. Medical Devices: Precision Surgical Tools, Imaging Equipment. Energy: Wind Turbine Bearings, Oil & Gas Drilling Components.
Manufacturing Processes:
Waterjet Cutting,Heat Treatment,Precision Machining
Highlight:

Stainless Steel Waterjet Cutting Services

,

Precision Waterjet Cutting Services

Product Description
Precision Waterjet Cut Stainless Steel Bearing Rings
Our Waterjet-Cut Stainless Steel Bearing Rings are engineered for high-performance applications demanding extreme precision, durability, and resistance to harsh environments. Crafted from premium 440C stainless steel using advanced waterjet cutting technology, these bearing rings deliver exceptional performance in critical industrial, automotive, aerospace, and marine applications.
Key Specifications
  • Material440C Martensitic Stainless Steel
  • HardnessHRC 58-60 (Heat-Treated)
  • Tolerance±0.05mm Inner Diameter
  • Size Range20mm to 500mm Customizable
  • Surface FinishRa ≤0.8μm
Features & Performance
Superior Material Properties
  • Excellent corrosion resistance for humid, marine, and high-stress environments
  • High tensile strength (up to 1,900 MPa) and fatigue resistance
  • Optimal wear resistance for heavy-load applications
Precision Manufacturing
  • Waterjet cutting eliminates thermal distortion
  • Burr-free edges and dimensional stability
  • Customizable outer diameter and thickness tolerance (±0.1mm)
Core Advantages
  • Micron-Level Accuracy: ±0.05mm ID tolerance for high-speed bearings
  • Zero Heat-Affected Zone: Preserves material integrity and hardness
  • Exceptional Durability: Resistance to abrasion, galling, and deformation
  • Fast Turnaround: Flexible production for small to large batches
  • Eco-Friendly Process: Minimal waste and no hazardous emissions
Applications
  • Aerospace: Landing gear systems, turbine components
  • Automotive: High-performance engines, transmission systems
  • Industrial Machinery: Robotics, CNC equipment, hydraulic presses
  • Marine & Offshore: Propulsion systems, saltwater-resistant assemblies
  • Medical Devices: Precision surgical tools, imaging equipment
  • Energy: Wind turbine bearings, oil & gas drilling components
Certifications & Compliance
  • ISO 9001:2015 Certified Manufacturing
  • Material Test Reports (MTRs) Available
  • RoHS & REACH Compliant
  • ASTM A276 Standards
Manufacturing Process
Process Stage Technical Content Purpose
Waterjet Cutting Ultra-high-pressure waterjet (6,000 Bar) with abrasives cuts plates/bars into ring blanks Rapid near-net shaping, achieving ±0.1mm initial accuracy with no thermal deformation
Heat Treatment Vacuum quenching (1,040-1,060°C) + Low-temperature tempering (150-370°C) Achieve target hardness (HRC 58-60) and eliminate internal stresses
Precision Machining CNC grinding machines for inner diameter finishing (±0.05mm tolerance) + polishing (Ra ≤0.8μm) Finalize dimensional accuracy and surface smoothness for seamless assembly
Process Comparison
Process Type Typical Process Application Scenarios Limitations
Forging + Machining Forging blank → Rough machining → Heat treatment → Finishing High-strength components in mass production (gears, shafts) Large heat-affected zone, difficult tolerance control (±0.1mm or above), high cost
Casting + Machining Casting → Sand cleaning → Heat treatment → Finishing Complex-shaped components (casings, brackets) Risk of porosity, rough surface, low precision (±0.2mm or above)
Stamping + Machining Stamping → Deburring → Finishing Thin-walled parts and standardized components (gaskets, flanges) Suitable only for simple shapes, high mold cost, limited material hardness
This Product Waterjet cutting → Heat treatment → Precision machining High-hardness, high-precision, small-batch customized components Advantages: No thermal deformation, ±0.05mm tolerance, hardness retention
Tags:

Forged Rings,

Metal Flange Ring,

Forged Metal Rings
