Precision Waterjet Cutting Services Forged Aluminum Alloy Solar Clamps 6061-T6
  • name

Precision Waterjet Cutting Services Forged Aluminum Alloy Solar Clamps 6061-T6

MOQ: 1PCS
Standard Packaging: Standard Export Package
Detail Information
Product Description
Detail Information
Place of Origin
CHINA
Brand Name
JIMAFor
Certification
ISO9001-2008,SGS,ROHS.
Product Name:
Precision Forged Waterjet Cut Aluminum Alloy Solar Clamps 6061-T6 ±0.1mm Tolerance Rapid Installation
Sample:
Can Be Customized
Applications:
Floating Solar Systems: Saltwater-resistant For Offshore Installations. BIPV (Building-Integrated PV): Aesthetic Anodized Finish For Architectural Projects. Solar Trackers: Precision Alignment For Dual-axis Tracking Systems.
Material:
6061-T6 Aluminum Alloy (Forged + T6 Heat-Treated)
Highlight:

Forged Waterjet Cutting Services

,

Aluminum Alloy Waterjet Cutting Services

,

Precision Waterjet Cutting Services

Product Description
Precision Waterjet Cutting Services Forged Aluminum Alloy Solar Clamps 6061-T6
Precision Forged & Waterjet-Cut Aluminum Alloy Solar Clamps | 6061-T6 | ±0.1mm Tolerance | Rapid Installation
Product Overview
Our Forged Aluminum Solar Mounting Clamps are engineered for high-load, precision-critical photovoltaic systems. Combining aerospace-grade 6061-T6 forging with ultra-precise waterjet cutting technology, these clamps deliver unmatched strength-to-weight ratios and seamless compatibility with solar panels, rails, and tracking systems.
Features & Specifications
Advanced Material & Manufacturing
  • Material: 6061-T6 Aluminum Alloy (Forged + T6 Heat-Treated)
  • Mechanical Properties: Tensile Strength: ≥310 MPa | Yield Strength: ≥275 MPa | Elongation: 12%
  • Corrosion Resistance: Anodized (20-25μm, MIL-A-8625) for salt spray/UV resistance
  • Core Process: Precision closed-die forging enhances grain structure and fatigue resistance
  • Waterjet Cutting: Abrasive waterjet (4,200 Bar) cuts clamp profiles with ±0.1mm tolerance, eliminating thermal distortion
Precision Engineering
  • Dimensional Accuracy: Clamp Inner Diameter: ±0.1mm | Bolt Hole Positioning: ±0.2mm
  • Universal Fit: Compatible with 30-50mm panel frames (Schletter, Unirac, etc.)
  • Load Capacity: Static Load: 2,000N | Dynamic Load (Wind/Snow): 1,200N (IEC 61215 Certified)
  • Surface Finish: Anodized Matte Black (Non-Reflective) | Optional PTFE Coating for Reduced Friction
Technical Specifications
  • Size Range: 30mm, 35mm, 40mm, 50mm (Custom Sizes Supported)
  • Weight: 200g/Unit (20% Lighter than CNC-Machined Alternatives)
  • Temperature Range: -50°C to +150°C (Arctic to Desert Environments)
  • Standards: ISO 9001, UL 2703, TÜV Rheinland 2 PfG 2681
Key Advantages
  • Forged + Waterjet Cutting Synergy: Forging enhances material density and fatigue life vs. cast/extruded aluminum. Waterjet provides burr-free, stress-free cutting with ±0.1mm precision without weakening heat-treated 6061-T6
  • Lifetime Durability: Anodizing warranty against corrosion (C5-M marine environment certified). Zero maintenance with self-locking stainless steel fasteners
Manufacturing Process
Process Stage Technical Content Purpose
Forging Closed-die forging of 6061-T6 billets under 400°C Refine grain flow, eliminate porosity
Waterjet Cutting 5-axis abrasive waterjet cuts clamp profiles (±0.1mm) Achieve complex shapes with no HAZ
T6 Heat Treatment Solution heat treatment + artificial aging Restore strength post-cutting (≥310 MPa)
CNC Finishing Drill bolt holes and deburr edges (±0.2mm accuracy) Ensure seamless rail/panel alignment
Anodizing Type III hardcoat anodizing (25μm) Salt spray resistance >1,500 hours
Quality Control 3D CMM + load fatigue testing (50,000 cycles) Certify IEC/UL/TÜV compliance
Applications
Utility-Scale Solar Farms: High-wind regions requiring rigid, lightweight clamps
Floating Solar Systems: Saltwater-resistant for offshore installations
BIPV (Building-Integrated PV): Aesthetic anodized finish for architectural projects
Solar Trackers: Precision alignment for dual-axis tracking systems
